  • Brand   Tipower
  • Type   100QJ16
  • Inquire Now

   For water supply from wells or reservoirs.
   For domestic use.
   For civil and industrial applications.
   For garden using and irrigation.

Operating conditions
   Maximum fluid temperature up to +55℃ .
   Maximum sand content: 0.25%.
   Maximum immersion :40m.
   Minimum well diameter :4".

Motor and Pump
   Rewindable motor or Full obturated screen motor
   Three-phase: 380V-415V/50Hz
   Single-phase: 220V-240V/50Hz
   Equiped with start control box or digital auto-control box
   Pumps are designed by casing stressed
   NEMA dimension standards
   Curve tolerance according to ISO 2548
