  • Brand   Tipower
  • Type   YL
  • Inquire Now


YL series single phase dual-capacitor asynchronous motor desiged and manufac-tured  according with IEC standard
These motors are widely used on air compressors,pumps,fans,refrigerator,medical instruments,small-size machines etc,

especially for occasion where only single-phase power supply is avaiable.

Operating Conditions
Ambient temperature : -15040
Altitude: Not exceeding 1000 meters
Rated voltage: 220V5%
Rated frequency: 50HZ
Duty/Rating: Continuous running
Insulation class: Class B/F
Protection class: IP44/IP54
Cooling type: Ic0141
