DC Solar pump

2015-3-27      View:
  • Brand   Tipower
  • Type   DC Solar pump
  • Inquire Now


For water supply from wells or reservoirs
For domestic use, for civil and industrial applications

For garden use and irrigation

Maintenance-Free Brushless DC Motor

Suitable for 24-48 Volt DC Operation
No electronics in the motor

Control inputs for well probe,dry running protection,remote control etc.
Integrated DSP & MPPT(Maximum Power Point Tracking)
Battery Operation,low voltage disconnect for battery system operation
Adjustable speed control of motor
Protection against reverse polarity,overload and high temperature


1.Application innovation
Compared with the traditional alternating current machine, the efficiency is improved 25% by the permanent magnetism, direct current, brushless, non-sensor motor.
2.Technics innovation
Adopt double plastic package for rotor and stator, motor insulation>300MW, the motor security was much improved.
3.Structure innovation

Oil filling, convenient installation and environmental protection
