  • Brand   Tipower
  • Type   Y
  • Inquire Now



Y series motor is a kind of low-voltage 3-phase cage induction motor. Which is a basic series for general uses.
This series motors can meet requirements for general uses at home and abroad with frame range 80-315 and it's a new product with the national unified design.
Y series has the advantages of high efficiency, energy saving, fine operation performance, small vibration, low noise, long service life, high reliablility, convenient
maintenance, big breakaway tor que, Fixing measurement and power grade completely conform to IEC standard. It enploys Grade B insulation, IP44 class for shell protection and IC411 cooling mode.
Y connection is adopted for motors below 3KW and "Δ" commection is adopted for those above 4KW.
Y series motor is commonly applied in machinery and equipment without special requirements, such as agricultural machinery, food machinery, fan, agitator and air compressor, etc.

Operating Conditions
Ambient temperature: -15040
Altitude : Not exceeding 1000 meters
Rated voltage: 380V 5%
Protection type: IP44/IP54
Connection: Y Start-Connection for 3kw and below
Date-Connection for 3kw or more
Cooling type: IC0141
Insulation class: Class B/Class F
Rated frequency: 50HZ/60HZ
